Soxhlet Extraction Apparatus HmbG

  • Boro3.3
  • Extraction Thimble sold separately
  • Additional info:
    – Extraction Thimble 33×100 mm fit for G1590B



Description

Complete set

Code No. Unit Condenser Extraction Chamber Flat Bottom Flask
G1590B 1 set 250mm, C40/38 100ml, Chamber D x 120mm, S40/38, C24/29 250 ml, S24/29

Condenser

Code No. Unit Jacket Length Socket Cone OD Jacket Overall Length
G1589 1 pc 250 mm 40/38 37 mm 390

Extractor

Code No. Unit Capacity Chamber OD Chamber Length Socket Cone Overall Length
G1552 1 pc 100ml 45 mm 120 mm 40/38 24/29 260 mm

Flat Bottom Flask

Code No. Unit Capacity Body Dia. Height Socket
G0176 1 pc 250 ml 85 mm 137 mm 24/29
