Specification | |
Code | A0628 |
Total Magnification | 20X or 40X by rotating the 2X/4X |
Head | Binocular 45º inclined, Fixed, Forward-directed, Interpupilary Distance 55mm-75mm |
Eyepiece | WF10x/20mm, pair |
Diopter Adjustment | Left Ocular tube with diopter adjustment ±5 |
Objective | Turret Objective 2X/4X |
Focus | All metal rack-and-pinion focusing, focus knob has tension adjustment |
Working Distance | 55mm |
Stage | Stage with stage clips, φ95mm frosted glass stage plate and φ95mm reversible white/black stage plate. Base Size: 115x165x63mm |
Illumination | Halogen bulb 12V 10W Up/Bottom Light |
Power | 110-240V AC Power Supply, UK Plug |
Product Dimension | L115xW230xH285 mm |
Eyepiece | Turret Objective 2X/4X | |
W.D. 55mm | ||
Mag. | F.O.V | |
10x/20mm | 20X/40X | 10mm/5mm |
