Specification |
Code |
A4621 |
Model |
506-F |
Total Magnification |
40X~2000X |
Head |
Seidentopf Binocular 45º inclined 360º Rotatable |
Eyepiece |
WF10x/18mm (pair), WF20x (pair) |
Objective |
Achromatic 4X, 10X, 40X (Spring), 100X (Spring, Oil) |
Nosepiece |
Quadruple Revolving Nosepiece |
Focusing |
Coaxial Coarse and Fine Focus Adjustment |
Condenser |
Abbe Condenser N.A.1.25 with Iris Diaphragm, with Filter Holder |
Stage |
Double Layer Mechanical Stage 125x110mm |
Illumination |
1W LED, Brightness Adjustment |
Power |
210~230V AC Power Supply, UK Plug, 50Hz |
Product Dimension |
L180xW225xH345mm |
